MidNite Solar MNEDC30, PNL Mount, 30A, 120VAC, 150VDC

MidNite Solar MNEDC30 PNL Mount 30A 120VAC and 150VDC Breaker

MidNite's breakers are rated to break the full rated load at the rated voltage repeatedly, with NO DAMAGE. Always use a properly sized breaker for disconnecting.

All MidNite circuit breakers can be used at 100% rated current when mounted in a MidNite enclosure.

• NON POLARIZED
• Listed for 120vac and 150vdc
• Width 0.75 inch
• 1/4 inch studs
• Breaker Torque Value: 30 In-Lbs (3.4NM)
• Environmental Rating - Type 1 (Indoor)
• Listed for US & Canada when used in appropriate breaker box
• Includes two 6-32 x 0.195” Pan Head Phillips mounting screws
